The Aggressive Solution for Heavy Rust & Paint Removal Engineered for brute-force surface preparation, this 1500W Continuous Wave (CW) laser cleaner aggressively strips away thick rust, heavy oxidation, and industrial coatings. Powered by a top-tier MAX laser source and kept optimal by a genuine S&A CWFL-1500 water chiller, it guarantees relentless 24/7 operation. Running on an accessible 220V single-phase supply, it brings heavy-duty cleaning power to any standard workshop without requiring electrical upgrades.
-
Core Capabilities: Heavy rust eradication, thick paint stripping, structural steel prep.
-
Premium Hardware: SUP22C cleaning head with up to 300mm scanning width.
-
Ideal For: Auto frame restoration, steel fabrication shops, and agricultural equipment maintenance.
Brand - GLOBAL LASER
Maker - China GLOBAL LASER Co., Ltd.
Table Size -
Rating -
4.73
Price -
$4,000.00
Note -
$4,000 - $5,500
for Basic & Pro Editions
Continuous Laser Cleaning Machine Technical Parameters
| Parameter | QYCL-FC1500 | QYCL-FC2000 | QYCL-FC3000 |
|---|---|---|---|
| Laser Power | 1500W | 2000W | 3000W |
| Laser Type | Continuous (CW) | Continuous (CW) | Continuous (CW) |
| Laser Source Brand | MAX | MAX | MAX |
| Optical Fiber Cable Length | 10m (15m optional) | 10m (15m optional) | 20m (30m optional) |
| Controller | SUP-22C | SUP-22C | SUP-22C |
| Laser Cleaning Head | SUP22C | SUP22C | SUP22C |
| Cooling Type | Water Cooled | Water Cooled | Water Cooled |
| Water Chiller | S&A CWFL-1500 | S&A CWFL-2000 | S&A CWFL-3000 |
| Voltage | 220V, single phase | 220V, single phase | 380V, 3 phase |
| Power Consumption | 7.7kW | 10kW | 12.6kW |
| Electric Current | 35A | 45A | 25A |
| Power Adjustment Range | 10-100% | 10-100% | 10-100% |
| Mode of Output | QBH | QBH | QBH |
| Scan Width | 10-150mm (400mm focus lens) / 10-300mm (800mm focus lens) | 10-150mm (400mm focus lens) / 10-300mm (800mm focus lens) | 10-150mm (400mm focus lens) / 10-300mm (800mm focus lens) |
| Focus Lens | F400/F800 | F400/F800 | F400/F800 |
| Central Wavelength | 1070~1090nm | 1070~1090nm | 1070~1090nm |
| Temperature of Water | 22℃-26℃ | 22℃-26℃ | 22℃-26℃ |
| Cooling Water | Distilled water, Plasma water | Distilled water, Plasma water | Distilled water, Plasma water |
| Cleaning Head Protective Lens Spec | D30×T5 | D30×T5 | D30×T5 |
| Cleaning Head Focusing Lens Spec | D20×3.5 F400 / D20×3.5 F800 | D20×3.5 F400 / D20×3.5 F800 | D20×3.5 F400 / D20×3.5 F800 |
| Cleaning Head Collimator Lens Spec | D16×5 F60 | D16×5 F60 | D16×5 F60 |
| Cleaning Head Weight | 0.8kgs | 0.8kgs | 0.8kgs |
| Machine Size | 92×49×85cm | 111×49×85cm | 124×51×114cm |
| Packing Size | 109×60×115cm = 0.75CBM | 122×58×115cm = 0.81CBM | 132×59×151cm = 1.18CBM |
| Net Weight of Machine | 105kgs | 130kgs | 190kgs |
| Package Weight | 170kgs | 200kgs | 300kgs |
| Air Assist | Filtered and dried compressed air | Filtered and dried compressed air | Filtered and dried compressed air |
| Recommended Air Pressure | 0.6-0.8Mpa | 0.6-0.8Mpa | 0.6-0.8Mpa |
Heavy Industry • Continuous Wave
1500W CW Laser
Cleaning Machine
Sandblasting is toxic, messy, and heavily regulated. The GL-CW1500 replaces outdated abrasive methods with pure, continuous thermal energy. Operating at 1500W, this system doesn’t just clean—it obliterates thick oxidation, heavy industrial paints, and persistent grease from massive steel structures, drastically reducing your surface preparation time.
- Continuous Wave Power: Unbroken laser delivery for melting away the thickest contaminants.
- Ultra-Wide Scanning: Adjustable beam width up to 300mm for massive surface coverage.
- Non-Contact Process: No media cleanup, no chemical disposal, just pure light extraction.
Built for the Toughest Environments
This is not for delicate molds. The 1500W CW is designed for aggressive surface prep where massive heat and power are required.
Shipyards & Marine
Rapidly strip anti-fouling paint, extreme saltwater corrosion, and barnacle residue from massive ship hulls and dock structures.
Steel Structure Prep
Prepare H-beams, bridges, and construction steel for welding or coating by instantly vaporizing mill scale and deep-pitted rust.
Heavy Machinery Rehab
Refurbish mining equipment, tractors, and railcars by burning away layers of caked-on grease, oil, and industrial dirt in a single pass.
System Specifications
| Laser Power | 1500W |
|---|---|
| Laser Mode | Continuous Wave (CW) |
| Max Scanning Width | Up to 300 mm |
| Cooling System | Industrial Dual-Temperature Water Chiller |
| Fiber Cable Length | Standard 10 Meters (Extended options available) |
Test the 1500W Against Your Worst Rust.
Don’t take our word for it. Send us your thickest, most corroded steel sample or an epoxy-coated plate. Our engineers will blast it with the 1500W CW system and send you the uncut video proof of the results.
