Pulse Cleaner - Air-Cooled

Pulse Cleaner - Air-Cooled

Brand - GLOBAL LASER
Maker - China GLOBAL LASER Co., Ltd.
Table Size -
50*50*55
Rating -
4.69
Price -
Note -
$10000-$15000
for Basic & Pro Editions
300 Units in Stock Available for Sale Every Month
Meeting CE Standards in Terms of Quality & Safety
1-Year Limited Warranty (Extended Coverage for Major Parts Available)
Free Lifetime Technical Support for End-Users & Dealers
Global Logistics and International Shipping To Anywhere
Get a Quote
Product inquiry
Incoming Material Inspection + Process QC Records Available
Power Calibration Report Available Upon Request
Burn-In Test Completed Before Delivery

Laser Cleaning Machine Full Parameters

Operating Environment

Parameter Specification
Power Supply Voltage Single-phase 220V±10%, 50/60Hz AC (Customizable: 110V, 50Hz AC)
Total Power Consumption ≤1500W
Operating Ambient Temperature 5℃~40℃
Operating Ambient Humidity ≤80%

Optical Parameters

Parameter Specification
Average Laser Power ≥200W
Power Stability <5%
Laser Operating Mode Pulsed
Pulse Width 2-500ns (Adjustable)
Maximum Single Pulse Energy 5mJ
Power Adjustment Range 0-100% (Gradual adjustment)
Frequency Adjustment Range 1-4000kHz (Gradual adjustment)
Optical Fiber Length 5m
Cooling Method Air-cooled

Cleaning Head Parameters

Parameter Specification
Scanning Range (L*W) 0-145mm (Continuously adjustable); Dual-axis supports 9 scanning modes
Field Lens Focal Length 210mm (Optional: 160mm/254mm/330mm/420mm)
Depth of Focus Approx. 10mm

Mechanical Parameters

Parameter Specification
Overall Machine Dimensions (L*W*H) Approx. 740mm*360mm*734mm
Dimensions After Packaging (L*W*H) Approx. 800mm*430mm*890mm
Overall Machine Weight Approx. 52KG
Weight After Packaging Approx. 67KG
Cleaning Head Weight (Excl. Optical Head) <0.9Kg
Operation Mode Handheld / Automated
